Your benefits at a glance

Fall prevention
The side guards extend over almost the entire length of the stretcher and can thus additionally support fall prevention measures.

Soft drop function
Thanks to the soft drop function, the side rails can be lowered smoothly, gently and quietly.

Easy handling
The side rails can be lowered quickly from both ends of the stretcher, so that of the stretcher so that unimpeded access to the patient is possible

Cardiac chair position
The sprint 100 can be moved from a flat lying position to the cardiac chair position for optimal treatment and care of the patient.
Breathing and circulation can thus be supported effectively and quickly even in critical situations.

Simple adjustment option
With hydraulics and gas spring mechanism, the transport couch with 4-section mattress support surface can be easily and quickly brought into the cardiac chair position.

Optimal patient access
Treatments can be performed more easily when the patient is in a sitting position.
This additionally supports the patient's comfort, well-being and safety.



As needed
With the four-sided braking system, access to the brake is guaranteed at all times and enables a fast reaction time and thus transport without unnecessary
loss of time. The accessibility of the brake function is on demand and without additional loss of time due to the change of position.

Light and simple
The brakes are easy to release and are activated by pushing the foot lever down instead of pulling it up in each case. This minimizes the effort required and supports ergonomic working.

Good driveability
The retractable 5th roller allows the sprint 100 to be driven and maneuvered smoothly over uneven floors and possible obstacles such as elevator entrances and thresholds. This significantly increases patient comfort and safety. To achieve better shock absorption, the castor is spring-loaded. With its diameter of 16mm, obstacles can be easily overcome.

Underride capability
To make the stretcher fully compatible for the use of different medical equipment such as C-arms or X-ray equipment, the 5th roller can be retracted or extended. By simply pressing the foot lever, the
5th roller is retracted under the chassis, making room for undercarriage of medical equipment.

Safe, practical and operable with one hand
In clinical practice, integrated infusion stands on transport couches are often used as push handles. The sprint 100 offers a safer and more practical design here, where the infusion stands can be pushed in and folded away with one hand. Common infusion stands often break when used as push handles. The IV&Drive feature of the sprint 100 is particularly robust, both to minimize the risk of damage and associated follow-up costs, and to optimize procedures for staff.

Beneficial for all
The IV&Drive function has been developed to improve the practicality and safety of the stretcher, reduce follow-up costs, and provide ergonomic support for personnel in their operations.

Technical features



2-section platform

4-section platform

Safe working load (SWL)

320 kg

320 kg

Overall length

211 cm

211 cm

Overall width

76 cm

76 cm

Height adjustment

56.5–89 cm

55.5–88 cm

Mattress dimensions

193 × 66 cm

193 × 66 cm

Castors diameter

20 cm

20 cm

FlexiDrive diameter

20 cm

20 cm

Positioning

2-section platform

4-section platform

Backrest angle

0–90°

0–90°

Tightrest angle

-

0–40°

Calfrest

-

0–17°

TR/ATR tilt

+/− 18°

+/− 18°

Siderails

2-section platform

4-section platform

Height

35.5 cm

36.5 cm

Amount of bars

6

6

Distance between bars

21 cm

21 cm

Maximum recommended mattress height

13 cm

13 cm
